1032 / 1042 / 1132 Series Low Pressure Brass Diaphragm Valves
Please call so that we can give you up-to-date quotes for these valves!
Sherwood's 1032 Series is designed for use in liquefied gas applications, including with refrigerants and flammables. These valves are especially suitable for propane, butane and fuel-gas applications, as well as sterilant gas applications.
High-density forged brass body and two non-perforated stainless steel diaphragms for durability
Spring-loaded Type CG-7 safety for use on liquified gas cylinders having water capacities not exceeding 254 lbs
Nylon seat insert and controlled stem travel assure positive shut-off and long, wear-resistant service
Inlet and outlet connections comply with CGA V-1 Specifications
Assembly torque: Bonnet 60 ft-lbs
Login to check prices
| SKU | DESCRIPTION | MANUFACTURER |
|---|---|---|
| 1042X6T | Low Press Brass Valve, CGA 510 outlet, 3/4" inlet, 1/4" inlet tap, no PRD, Kel-F seat | Sherwood Spec |
| 1132T510-375 | Low Pressure Brass Diaphragm Valve, 3/4 - 14 NGT, 555, 375 PSIG | Sherwood Spec |
| 1132T555-375 | Low Pressure Brass Diaphragm Valve, 3/4 - 14 NGT, 510, 435 PSIG | Sherwood Spec |
| 1132X8510 | Low Pressure Brass Diaphragm Valve, 3/4 - 14 NGT, 510 | Sherwood Spec |
| 41-P1032-7A | PTFE-Coated Operating Stem | Sherwood Spec |
Sherwood_1032_Series.pdf
